What fits on the tray. What the crane lifts.
Hino 500 flatbed with a Palfinger PK 15500 HIAB crane. 10.1 metres of reach, up to 6,200 kg of lift. Here's the full chart so you can see exactly what we can move.
Palfinger PK 15500. Rear-mounted HIAB.
Three boom configurations (Std, B, B+) let us trade off reach against lift weight. Short boom picks up the heavy stuff. Full extension reaches further for lighter loads.
- Max reach
- 10.1 m
- Mode B+, fully extended
- Max lift
- 6,200 kg
- Mode Std, short reach
- Lift at 4.5 m
- 3,260 kg
- Mode Std
- Lift at 10.1 m
- 1,230 kg
- Mode B+, max reach
Lift weight at each reach.
Based on the PK 15500 data plate. Each row is a boom configuration, each column is a reach distance. Pick the heaviest lift we can safely do at the distance your job needs.
| Mode | Max | 4.5 m | 6.1 m | 8.0 m | 10.1 m |
|---|---|---|---|---|---|
| Std | 6,200 kg | 3,260 kg | 2,380 kg | — | — |
| B | 6,100 kg | 3,140 kg | 2,250 kg | 1,690 kg | — |
| B+ | 6,000 kg | 3,040 kg | 2,140 kg | 1,570 kg | 1,230 kg |
These are the crane's rated capacities from the manufacturer. Actual lift limits on site depend on ground conditions, overhead clearance and outrigger position. We confirm every job before the lift.
7.8 metres long,
2.4 metres wide.
Long enough for a 20ft container, steel beams, or a spa end-to-end. Wide enough for two pallets across. Flat deck, rated for commercial and industrial loads.
- Length
- 7.8 m
- Width
- 2.4 m
What the truck is built for.
If it fits on the tray and the crane can lift it, we'll get it there. Typical loads we handle:
- Spas & plunge pools
- Sheds, studios, granny flats
- 20ft & 10ft shipping containers
- Water tanks
- Steel beams & structural
- Industrial machinery & plant
- Construction supplies & pallets
- Scaffolding
- Generators & switchboards
- Rooftop units (AC, solar, HVAC)
- Turf, bricks, pavers
- Pipes & poles
Not on the list? Most likely still fine. Tell us the job and we'll confirm.
A few things to tell us when you call.
Weight & size of the load
Rough weight and rough dimensions (L x W x H) let us confirm the lift is within range before we roll.
Site access
Driveway width, overhead powerlines, trees, and the distance the crane needs to reach from the truck parking spot.
When it needs to happen
Exact day, or a rough window. Most bookings land on the same day we talk or the next.
Got a load in mind?
Send it through.
We'll tell you whether it fits on the tray, whether the crane will lift it, and what it'll cost, usually on the call.
